• Country
• Spain

• Manufacturer / Brand
• Afha España, S.A.; Barcelona

• Year
• 1967 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 319404

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• ECC81

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Generador RF-BF 21/G/RF Repro - Afha España, S.A.; Barcelona

• Shape
• Book-shelf unit.

• Notes

• Afha España, S.A.; Generador de RF-BF 21/G/RF (G21/R) Repro

  Salida de RF de 300 kHz a 20 MHz en cuatro bandas.

  • 300 - 500 kHz, 500 kHz - 1,5 MHz, 4,7 - 7 MHz, 4 - 20 MHz.
  • RF regulable de 0-100 mV.
  • Salida señal de BF: 400 Hz regulable de 0 - 3 V.

  Diodo Rectificador de Selenio 25 mA, 135 V
