• Year
  • 1940–1945 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 330393

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 100-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
  • Power out
  • 2 W (4 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 1085 - Agris; Madrid
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 530 x 260 x 375 mm / 20.9 x 10.2 x 14.8 inch
  • Net weight (2.2 lb = 1 kg)
  • 7.5 kg / 16 lb 8.3 oz (16.52 lb)
