- Country
- Germany
- Manufacturer / Brand
- Ahemo-Werkstätten; Berlin-Charlottenburg:
- Year
- 1929/1930
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 13895
Radio Schnorr 1930
- Number of Tubes
- 5
- Main principle
- TRF with regeneration
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: A4W [RE604] - Ahemo-Werkstätten; Berlin-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 530 x 260 x 270 mm / 20.9 x 10.2 x 10.6 inch
- Notes
- Unterschiede zur alten Version: Netzteil auf Chassis integriert, alle Röhren senkrecht, Rückwand aus Metall, alle Anschlüsse hinten.
- Price in first year of sale
- 398.00 RM +
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Lehner & Küchenmeister 1929 / Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Radio Schnorr 1929
