• Country
• United States of America (USA)

• Manufacturer / Brand
• Aimcee Wholesale Corporation (AMC); New York, NY

• Year
• 1963 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 334488

• • alternative name: Associated Merchandising

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• 2SA240 2SA230 2SA93 2SA93 2SA93 2SB54 2SB54 2SB56 2SB56

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / AA: 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AMC 2 Band Transistor 9 9TF-82 - Aimcee Wholesale Corporation

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 180 x 94 x 48 mm / 7.1 x 3.7 x 1.9 inch

• Notes

• Identical to Singer HE-229 except for the badge.

  Made in Japan

• Author
• Model page created by David Erali. See "Data change" for further contributors.
