Stabilised Power Supply 705
Airmec Ltd.; Perivale
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Airmec Ltd.; Perivale
- Year
- 1954 ?
- Category
- Power supply/conditioner or battery or charger
- Radiomuseum.org ID
- 353609
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 100-130; 200-250 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stabilised Power Supply 705 - Airmec Ltd.; Perivale
- Shape
- Tablemodel, low profile (big size).
- Notes
-
- Output is a stabilised direct voltage variable continuously from 200 to 350 V at maximum current of 100 mA
- May be used either positive or negative line earthed or with the output floating.
- Output changes is less than ±0.5% for ±10% input change.
- Output change from full load to no load is +0 -0.5%.
- Both voltage and current meters are incorporated.
- An unstabilised alternating supply of 6.3 V the centre tap of which may be strapped to earth is also available.
- Mentioned in
- -- Original prospect or advert (From “Electronic Engineering”, year 1954, February.)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
