- Country
- Australia
- Manufacturer / Brand
- Airzone (1931) Ltd.; Sydney
- Year
- 1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 171255
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 1252V - Airzone 1931 Ltd.; Sydney
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- This model had a synchronous vibrator power unit.
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. IV
- Mentioned in
- Mingay's "Radio Diagram & I.F. Index
- Literature/Schematics (1)
- Radio & Electrical Retailer, Australia (27/5/1943, Page 16.)
- Literature/Schematics (2)
- Australian Official Radio Service Manual AORSM (Volume 4, 1941, Page 34.)
