Airzone (1931) Ltd.; Sydney
- Country
- Australia
- Manufacturer / Brand
- Airzone (1931) Ltd.; Sydney
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 162205
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 565 Ch= 516 - Airzone 1931 Ltd.; Sydney
- Shape
- Console with any shape - in general
- Notes
-
As originally released, this model was fitted with metal-envelope valves & the chassis type number was 516. Later an alternative receiver using an identical circuit but with standard glass valves was released under model 568 and the chassis designated 526. A slightly different set of operating voltages applies for the later model. However apart from this the schematics are identical.
- Price in first year of sale
- 28.75 AUS £
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. I
- Literature/Schematics (1)
- Radio Trade Annual of Australia (6th Edition 1938, Page 237.)
- Literature/Schematics (2)
- Australian Official Radio Service Manual AORSM (Volume 1, 1938, Page 21.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
