- Country
- Australia
- Manufacturer / Brand
- Airzone (1931) Ltd.; Sydney
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 190195
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 210; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: 5A1A2 - Airzone 1931 Ltd.; Sydney
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 365 x 250 x 205 mm / 14.4 x 9.8 x 8.1 inch
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. IX
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
