• Country
• Japan

• Manufacturer / Brand
• Aiwa Co. Ltd.; Tokyo

• Year
• 1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 136196

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 31

• Semiconductors

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 110-120/220-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: AD-1300EE - Aiwa Co. Ltd.; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 407 x 102 x 261 mm / 16 x 4 x 10.3 inch

• Notes
• Stereo Cassettendeck mit Dolby B-System. 3-Stufen-Bandwahlschalter. Plexiglasschutzhaube.
  30 - 15000 Hz.
  31 Transistoren, 23 Dioden und 2 FET's.

• Net weight (2.2 lb = 1 kg)
• 5.1 kg / 11 lb 3.7 oz (11.233 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
