• Country
• Japan

• Manufacturer / Brand
• Aiwa Co. Ltd.; Tokyo

• Year
• 1999 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 324661

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 450/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110-120; 220-240 / C: 8 x 1.5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 8 cm = 3.1 inch

• Power out
• 3.8 W (5 W max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Compact Disc Stereo Radio Cassette Recorder CSD-ED27 - Aiwa Co. Ltd.; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 310 x 156 x 253 mm / 12.2 x 6.1 x 10 inch

• Notes
• • FM Tuner 87.0 - 108.0 MHz
  • AM Tuner 530 - 1710 kHz (10 kHz step) or 531 - 1602 kHz (9 kHz step)
  • 15 preset stations in each band
  • Stereo Cassette player
  • Compact Disc player
  • Stereo mini jack for headphones
  • Virtual Stereo, 3-Mode Equalizer
  • Sleep timer

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
