Stereo Radio Cassette Recorder HS-J707

Aiwa Co. Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1992 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 146987

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / AAA: 2 x 1.5 or Pb: 1 x 2 / DC 2 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Stereo Radio Cassette Recorder HS-J707 - Aiwa Co. Ltd.; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 80 x 110 x 30 mm / 3.1 x 4.3 x 1.2 inch
  • Notes

  • AM/FM Radio-Cassettenrecorder. Dolby B, DSL.
    3-fach Auto-Reverse, 30 -18.000 Hz (Metall).
    Tuner mit 10 Stationsspeicher. Multi-Time-Display.

    • eingebauter Lautsprecher abschaltbar
    • mit Uhranzeige
    • DSL schaltbar on-off
    • FM Mode mono-stereo schaltbar
    • Mikrofoneingang

    Komplett mit Bügel-Kopfhörer, Stereo-Mikrofon, Akku (PB-3), Lade-Netzteil, Tasche und Batteriefach.
    Gehäuseausführung Schwarz.

  • Net weight (2.2 lb = 1 kg)
  • 0.2 kg / 0 lb 7 oz (0.441 lb)
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
