Stereo Cassette Recorder HS-F07

Aiwa Co. Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1984 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 332960

 Technical Specifications

  • Number of Transistors
  • 28
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / AAA: 2 x 1,5 V / 3 Volt
  • Loudspeaker
  • - only for Earphone!
  • Power out
  • 0.02 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Recorder HS-F07 - Aiwa Co. Ltd.; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 83 x 115 x 25 mm / 3.3 x 4.5 x 1 inch
  • Notes

  • Autoreverse Stereo Casstten Recorder
    Metallausführung gold
    Kopfhörer-Anschluss
    Dolby NR
    Umschaltung Metal-Normal
    Bekannt aus dem Film "Zurück in die Zukunft"
    Electret Kondensator Mikrofon
    Umschaltung Reverse Mode
    Super Permalloy Head

    Transistoren mehrfach vorhanden

  • Net weight (2.2 lb = 1 kg)
  • 0.282 kg / 0 lb 9.9 oz (0.621 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual 5-1984)
  • Author
  • Model page created by Gerhard Härtl. See "Data change" for further contributors.
