LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K

Aiwa Co. Ltd.; Tokyo

Datos

Foro

Imágenes

Colecciones

País
Japon

Fabricante / Marca
Aiwa Co. Ltd.; Tokyo

Año
1979

Categoría
Radio - o Sintonizador pasado WW2

Radiomuseum.org ID
208633

Imágenes
Esquemas

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700291) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700292) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700293) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700294) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700295) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700296) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700297) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700298) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700299) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700300) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700301) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700302) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700303) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700304) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700305) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700306) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700307) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700308) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700309) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700310) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700311) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700312) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700313) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700314) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700315) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700316) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700317) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700318) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2700319) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2043275) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (3)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2702692) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (2)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2702693) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (2)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2702694) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (2)

LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K; Aiwa Co. Ltd.; Tokyo (ID = 2045097) Radio — Aiwa Co. Ltd.; Tokyo LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K (2)
Detlef Gerth

Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.

Especificaciones técnicas

Numero de transistores
Hay semiconductores.

Semiconductores

Principio principal
PLL, Phase-locked loop; ZF/IF 450/10700 kHz

Gama de ondas
OM, OL y FM

Especialidades
Hi-Fi equipment

Tensión de funcionamiento
Red: Corriente alterna (CA, Inglés = AC) / 120; 220; 240 Volt

Altavoz
- Este modelo usa altavoz exterior (1 o más).

Potencia de salida
120 W (undistorted)

Material
Metálico

de Radiomuseum.org
Modelo: LW MW FM-Stereo Synthesized Receiver 7800 AX-7800E / AX-7800K - Aiwa Co. Ltd.; Tokyo

Forma
Unidad para estanteria.

Ancho, altura, profundidad
500 x 120 x 440 mm / 19.7 x 4.7 x 17.3 inch

Anotaciones
A stereo receiver housed in a metal case with a digital frequency display, with a 3 Band AM/FM stereo quartz digital synthesized tuner and amplifier with continuous power output of 2 x 60 watts, 20Hz-20kHz, THD 0.05%. Terminals for two pairs of loudspeakers, headphone jack on the front, memory for 10 radio stations.

Versions/Power requirements
AX-7800E: 120V/220V/240V AC 50/60Hz switchable
AX-7800K: 240V AC 50/60Hz

Power requirements: 420 Watts (E), 500 Watts (K).

Ausgangsleistung 2x 60W. 2 Lautsprechergruppen schaltbar, Kopfhörerbuchse frontseitig, 10 Senderspeicherplätze.

Peso neto
10.5 kg / 23 lb 2 oz (23.128 lb)

Mencionado en
- - Manufacturers Literature (Aiwa AX-7800 brochure)

Documentación / Esquemas (1)
- - Manufacturers Literature (Instruction manual Aiwa AX-7800E)

Documentación / Esquemas (2)
Funkschau (21/1979, S. 1208 / Internationale Funkausstellung)

Autor
Modelo creado por Franz Scharner. Ver en "Modificar Ficha" los participantes posteriores.

Otros modelos
Donde encontrará 930 modelos, 881 con imágenes y 165 con esquemas.
Ir al listado general de Aiwa Co. Ltd.; Tokyo

Colecciones | Museos | Literatura

Forum
