1721-W

• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1973

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 144870

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1721-W - Akai Electric Co., Ltd.; Tokyo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 358 x 360 x 248 mm / 14.1 x 14.2 x 9.8 inch

• Notes
• 4-Spur-Stereo Tonbandgerät mit eingebauter Endstufe mit 2 Lautsprechern.
  Max. Spulengrösse 18cm, Bandgeschwindigkeit 19/9,5 cm/Sek., 30-14000 Hz.
  16 Transistoren und 4 Dioden.
  Gerät mit Holzabdeckhaube.

• Net weight (2.2 lb = 1 kg)
• 13.2 kg / 29 lb 1.2 oz (29.075 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
