4000-DS alt
Akai Electric Co., Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Akai Electric Co., Ltd.; Tokyo
- Year
- 1973
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 144869
vue de face de la mécanique après réparation
vue du circuit audio après réparation
vue du bloc têtes après remplacement
Vue du côté gauche sans le coffre
vue du côté droit après réparation
Akai Advertise 1973
Original prospekt in 1973.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 11
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: 4000-DS [alt] - Akai Electric Co., Ltd.; Tokyo
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 400 x 300 x 140 mm / 15.7 x 11.8 x 5.5 inch
- Notes
-
4-Spur-Stereo-Tonbandgerät mit 3 Tonköpfen, Hinterbandkontrolle, Multiplayback, Duoplay, Mischmöglichkeit von 2 getrennten Eingangssignalen, automatische Endabschaltung, Pausetaste.
Bandgeschwindigkeit 19/9.5 cm/sec., max. Spulengrösse 18cm, 30 - 17000 Hz.
11 Transistoren, 4 Dioden, 2 IC.
- Net weight (2.2 lb = 1 kg)
- 11.5 kg / 25 lb 5.3 oz (25.33 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
