AP-101C

• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1978

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 213734

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Details
• Record Player (not changer); Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: AP-101C - Akai Electric Co., Ltd.; Tokyo

• Shape
• Tablemodel, with any shape - general.

• Notes
• Akai semi-automatic belt drive turntable model AP-101C with Akai Cartridge, Dustcover, Pitch Control, 2 Speed (33 and 45 rpm).
  Akai AP-101 (without cartridge).

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
