Stereo Integrated Amplifier AM-2250

Akai Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1979 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 214732

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 60 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Integrated Amplifier AM-2250 - Akai Electric Co., Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 380 x 130 x 260 mm / 15 x 5.1 x 10.2 inch
  • Notes
  • Akai Stereo Integrated Amplifier Model AM-2250.
    2x 30 Watts into 8 Ohma, Bass-, Treble-Control, Loudness.
    Inputs Phono, Tuner, AUX, Tape1, Tape2.
    Speakers A, B, A + B.
    Design Silver.
  • Net weight (2.2 lb = 1 kg)
  • 6 kg / 13 lb 3.5 oz (13.216 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
