Stereo Integrated Amplifier AM-M7
Akai Electric Co., Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Akai Electric Co., Ltd.; Tokyo
- Year
- 1984 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 299185
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 90 W (max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Integrated Amplifier AM-M7 - Akai Electric Co., Ltd.; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 350 x 98 x 267 mm / 13.8 x 3.9 x 10.5 inch
- Notes
-
potenza uscita: 45 + 45 watt into 8 Ω (stereo) - frequency response: 5 Hz / 80 Khz - total harmonic distorsion: 0.02 % - damping factor: 35 - input sensitivity: 0.25 mV (MC) - 2.5 mV (MM) - 150 mV (line) - signal to noise ratio: 78 db (MM) - 98 db (line) - channel separation: 45 db (line) - output: 150 mV (line) - speakers load impedance: 4 Ω to 16 Ω - controllo volume/toni alti/bassi/balance - ingressi phono/tape/aux-dad - speakers: A -B - A+B - ampio display frontale con regolazioni a pulsanti - ingresso per cuffia frontale -Made in Japan.
- Net weight (2.2 lb = 1 kg)
- 6.5 kg / 14 lb 5.1 oz (14.317 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
