Dual 1/3 octave/ precision equalizer M-EQ 230
Alesis; Rhode Island
- Country
- United States of America (USA)
- Manufacturer / Brand
- Alesis; Rhode Island
- Year
- 1997
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 253601
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Powered by external power supply or a main unit. / 9 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Dual 1/3 octave/ precision equalizer M-EQ 230 - Alesis; Rhode Island
- Shape
- Rack
- Dimensions (WHD)
- 430 x 40 x 95 mm / 16.9 x 1.6 x 3.7 inch
- Notes
-
Frequency Response: 25 Hz to 20 kHz in 1/3 octave increments
Input
Number of channels: 2
Nominal level: 0 dBV
Maximum level: +18 dBV
Output
Number of channels: 2
Maximum level: +18dBV
Front Panel
Controls: 30 Bands, 1/3rd octave , ±12 dB, center frequencies set to ANSI and
ISO standards.
Indicators: Power, Signal Present, Clip and In/Out LEDs per channel
Switches: In/Out
Rear Panel
Jacks:
Input Left and Right: 1/4" and RCA
Output Left and Right: 1/4" and RCA
Power: Barrel Jack
Power Requirements 9 Volts AC, 7.5 V/A external transformer, UL approved.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
