II Skalenglas, scales, Skala, Scala, Dial Cadran alle - all - tous - tutte
Alle Firmen, EUROPA
- Country
- Europe
- Manufacturer / Brand
- Alle Firmen, EUROPA
- Year
- 1900–2010
- Category
- Miscellaneous (Other, Various) - see notes
- Radiomuseum.org ID
- 176457
Skala Minerva 517/1 (450 x 133 mm)
Skala Philips JR 21 914 (460 x 106 mm)
Skala Hornyphon 295 x 62 mm
Skala Kapsch Herold de luxe 439 x 96 mm
Skala Kapsch Mondial 3D 531 x 150 mm
Skala Philips JR 21931 531 x 150 mm
Skala Philips 21942 381 x 71 mm
Skala Philips JR 22044 551 x 108 mm
Grundig C 4100 automatic Skala
Skala Eumig 364 x 74 mm
Skala Kapsch Juwel UKW 439 x 94 mm
Philips Capella Reverbo B7X43A/62
Ingelen 540 GW Skala
Hornyphon Diplomat W554A Skala
Minerva Presto 543B/1 Skala
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Various materials
- from Radiomuseum.org
- Model: II Skalenglas, scales, Skala, Scala, Dial Cadran alle - all - tous - tutte - Alle Firmen, EUROPA
- Notes
-
Bitte hier nichts hochladen - Please do not upload anything here.
Bitte nur hier hochladen - Please upload only here:
III Skalenglas, scales, Skala, Scala, Dial Cadran
Siehe auch / See also: I Skalenglas, scales, Skala, Scala, Dial Cadran
The file name should get a suffix, stating width and height (in millimetres), see example below.
Der Dateiname bekommt als Suffix: Breite mal Höhe in mm. Beispiel siehe unten.
Le suffixe suivant doit être joint au nom de fichier: largeur x hauteur en mm. Voir les exemples ci-dessous.
Il suffisso del nome del file deve contenere larghezza ed altezza (in millimetri). Vedere gli esempi qui sotto.
El nombre del archivo debe llevar un sufijo, indicando la anchura y la altura (en milímetros), véase el ejemplo de abajo.
a_eumig_eumigette_380W_skale_300x80mm.
d_saba_bodensee_16_skala_350x95mm.
This model page is only for manufacturers in Europe.
Please select from "Schematics etc." under file name or size (suffix).
Dieses Modellblatt ist nur für Hersteller in Europa.
Bitte selektieren Sie aus der Liste "Techn. Unterlagen" nach Dateinamen oder Abmessungen (Suffix).
Cette page modèle est seulement pour les fabricants en Europe.
S'il vous plaît sélectionnez dans la liste dans le "Schémas" sous le nom de fichier ou la taille (suffixe).
Questa pagina è solo per i produttori europei.
Le scale parlanti/sintogrammi sono accessibili dall'elenco degli Schemi, ordinati per nome di file o la dimensione (suffisso).
Esta página es sólo para modelos fabricados en Europa.
Picando sobre "Esquemas" verá el listado y podrá bajar el modelo seleccionado.
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
- Other Models
-
Here you find 6 models, 5 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Alle Firmen, EUROPA
Collections
The model II Skalenglas, scales, Skala, Scala, Dial Cadran is part of the collections of the following members.
