Ambassador 17TT62 Ch= A2005
Ambassador (Allied Stores Purchasing); New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Ambassador (Allied Stores Purchasing); New York, NY
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 271973
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 13
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- from Radiomuseum.org
- Model: Ambassador 17TT62 Ch= A2005 - Ambassador Allied Stores
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Ambassador 17TT62 is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis A2005 and picture tube 17HP4 or 17RP4.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 352, Folder 3, Date 3-57)
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
