- Country
- United States of America (USA)
- Manufacturer / Brand
- Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
- Year
- 1949
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 31951
SAMS Photofact Volume 7 Folder 4911-12
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Main principle
- Superheterodyne (common); ZF/IF 455-10.7MH kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- - This model requires external speaker(s). / Ø 11.5 inch = 29.2 cm
- from Radiomuseum.org
- Model: Knight 14F490 - Allied Radio Corp. Knight,
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 19 = 1949 and before
- Mentioned in
- Photofact Folder, Howard W. SAMS (Volume 7 Folder 4911-12 05/1949)
