Knight-Kit Electronic VTVM 83Y125
Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
- Year
- 1963
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 215960
Allied Catalog No. 220, 1963, pg 40
Electronic Technician september 1958
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Knight-Kit Electronic VTVM 83Y125 - Allied Radio Corp. Knight,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 5.25 x 7.5 x 5.25 inch / 133 x 191 x 133 mm
- Notes
-
AC/DC/ohms vacuum tube voltmeter. See separate sheet for full specifications. This model was originally supplied as a kit.
Very similar model is the later Knight VTVM KG-620 (2 resistor changes).
- Net weight (2.2 lb = 1 kg)
- 2 lb (2 lb 0 oz) / 0.908 kg
- Price in first year of sale
- 26.95 USD
- Literature/Schematics (1)
- Allied Radio Catalog (Knight) (Cat No. 220, 1963, cover says New 1963 Kits pg 1-69, pg 40, VTVM 83Y125-J Kit $26.95)
- Author
- Model page created by David Leishman. See "Data change" for further contributors.
