• Country
• United States of America (USA)

• Manufacturer / Brand
• Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

• Year
• 1957

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 146583

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC83 or 12AX7 ECC83 or 12AX7 6AV6 6L6GB 6L6GB 6X5GT 6X5GT

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Line / Batteries (any type) / AC/DC 110 -120; 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Knight 93SZ506 - Allied Radio Corp. Knight,

• Shape
• Tablemodel, with any shape - general.

• Notes

• The Allied Radio Model Knight 93SZ506 is an AC - Battery Operated 5 Channel 25 Watt Audio Amplifier.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 1-58, Set 383, Folder 7)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
