7 Band Graphic Equalizer 3024

Alpine Electronics, Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 160843
    • Brand: Alpage

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 40 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 7 Band Graphic Equalizer 3024 - Alpine Electronics, Tokyo
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 150 x 42 x 149 mm / 5.9 x 1.7 x 5.9 inch
  • Notes

  • 7 band graphic equalizer amplifier. ± 12 dB at 60, 125, 250, 600 Hz, 1, 3.5,10 kHz.

    Made in Korea

  • Net weight (2.2 lb = 1 kg)
  • 1 kg / 2 lb 3.2 oz (2.203 lb)
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
