• Country
• Japan

• Manufacturer / Brand
• Alpine Electronics, Tokyo

• Year
• 1980

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 152781

• • Brand: Alpage

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Alpage Stereo Cassette Tape Deck FL-5100 - Alpine Electronics, Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 420 x 150 x 240 mm / 16.5 x 5.9 x 9.4 inch

• Notes
• Frontloading 2-Head Stereo Cassette Tape Deck with Dolby B, MPX Filter and Metal Tape Capability.
  3-Digit Mechanical Counter, Digital Peak-Reading Meters. Bias Fine Tune. Price in Italy in 1980: 351.000 ITL.

• Net weight (2.2 lb = 1 kg)
• 5.7 kg / 12 lb 8.9 oz (12.555 lb)

• Mentioned in
• Discoteca HiFi, Anno XXI, n. 208-209, Agosto-Settembre 1980, Italy

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
