• Country
• United States of America (USA)

• Manufacturer / Brand
• Altec Lansing Corp.; Oklahoma City (OK)

• Year
• 1959 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 158898

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 6BQ7A 6AB4 6BQ7A 6BA6 6BE6 6BA6 6BA6 6AU6 6AU6 6AL5 12AU7A

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: 306A - Altec Lansing Corp.; Oklahoma

• Shape
• Chassis only or for «building in»

• Notes

• The Altec Lansing model 306A is a mono FM-AM Tuner, with AFC; late units had a 'Multiplex' output.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 2-59, Set 431, Folder 4)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.

• Other Models

• Here you find 104 models, 102 with images and 38 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Altec Lansing Corp.; Oklahoma City (OK)
