Stereo Graphic Equalizer 1432A
Altec Lansing Corp.; Oklahoma City (OK)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Altec Lansing Corp.; Oklahoma City (OK)
- Year
- 1992 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 261266
Altec Lansing Manual
Altec Lansing Manual
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115, 230 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Graphic Equalizer 1432A - Altec Lansing Corp.; Oklahoma
- Shape
- Rack
- Dimensions (WHD)
- 483 x 88 x 235 mm / 19 x 3.5 x 9.3 inch
- Notes
-
Altec Lansing Stereo 31 Band Graphic Equalizer Model 1432A.
Frequency response: 20Hz to 20kHz
Signal to Noise Ratio: 85dB, Total harmonic distortion: 0.01%, Control Range: ± 12dB Frequency Bands:
20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800Hz
1K, 1.25K, 1.6K, 2K, 2.5K, 3.15K, 4K, 5K, 6.3K, 8K, 10K, 12.5K, 16K, 20KHz
Power Consumption 18 Watts.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
