- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1959
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 234798
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 6BQ7A 6CQ8 6CB6 6U8 6CB6 12BY7 6AU6 6AL5 6BV7 6SN7GTA 6AQ5 6SN7GTA 6DQ6A 6AX4GT 1B3GT 5AS4 21CBP4A
- Number of Transistors
- Semiconductors
- GEX34
- Main principle
- Superhet with RF-stage; ZF/IF 36000/30500 kHz; 1 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 200; 230; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 3 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 225 - Amalgamated Wireless
- Shape
- Console with any shape - in general
- Notes
-
21 inch B&W television receiver tunes the ten then standard Australian VHF channels.
Budget priced model similar in appearance to AWA 211T.
Cabinet finishes available in Walnut, Maple & Mahogany.
- Price in first year of sale
- 173.25 AUS £
- Literature/Schematics (1)
- - - Manufacturers Literature (AWA Manufacturers Supervised Service.)
- Literature/Schematics (2)
- J.R. Publications Television Service Handbook (L.J. Series Vol. 1, 1962 & 1967, Page A85.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
