- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1959
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 234799
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 6BQ7A 6CQ8 6CB6 6U8 6CB6 12BY7 6AU6 6AL5 6BV7 6SN7GTA 6AQ5 6SN7GTA 6DQ6A 6AX4GT 1B3GT 5AS4 21CBP4A
- Number of Transistors
- Semiconductors
- GEX34
- Main principle
- Superhet with RF-stage; ZF/IF 36000/30500 kHz; 1 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 200; 230; 240 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 228 - Amalgamated Wireless
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
21 inch B&W television receiver tunes the ten then standard Australian VHF channels.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- J. R. Publications "Television Service Handbook" Page A85.
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
