AWA All-Transistor Pressmatic 940CZ
Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1965
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 228854
- Number of Transistors
- 8
- Semiconductors
- 2N640 or. 2N1637 2N642 or. 2N1639 2N640 or. 2N1636 or. 2N1637 2N641 or. 2N1638 2N641 or. 2N1638 2N591 2N301 2N301
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 9 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 5 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: AWA All-Transistor Pressmatic 940CZ - Amalgamated Wireless
- Shape
- Chassis only or for «building in»
- Notes
-
Push button tuning. This model could be adjusted for use in either +ve or -ve chassis vehicles. It was originally supplied with a 7" by 5" speaker.
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
