• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Amalgamated Wireless Australasia (NZ) Ltd. (AWA); Wellington

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 342511

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECH81 EF89 EABC80 ECC83 EM84 ECC83 EL84 EL84

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• 2 Loudspeakers

• from Radiomuseum.org
• Model: AWA Radiola Wakefield AZ152 - Amalgamated Wireless

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• 8-Valve (including magic eye) 5 Band Console receiver.

  See schematic for alternative valve types.

  Telefunken 504 automatic 4 speed record changer.

  Two 6 x 10 permanent magnet elliptical speakers (one per channel).

  Manufactured by Allied Industries Ltd, Auckland for Amalgamated Wireless (Australasia) NZ Ltd.

• Price in first year of sale
• 159.50 NZ £

• Mentioned in
• -- Original prospect or advert (Press 20 Jul 1964 Page 13)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
