Tracker P5 Ch= 54-01
Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1970
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 214359
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 0
- Valves / Tubes
- 12CZP4
- Number of Transistors
- 28
- Semiconductors
- Main principle
- Superhet with RF-stage; ZF/IF 36875 & 31375 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Line / Batteries (any type) / 240; 250 or 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Tracker P5 Ch= 54-01 - Amalgamated Wireless
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 400 x 311 x 254 mm / 15.7 x 12.2 x 10 inch
- Notes
-
Portable 12" B&W television set tuning standard 12 Australian VHF TV channels. D.C. input 11.5 to 17 V @ 1.75 A. As well as the transistors, a CA3042 I.C. is used.
Colours available in Tango Red, GT Gold & Shell White.
- Net weight (2.2 lb = 1 kg)
- 10.440 kg / 22 lb 15.9 oz (22.996 lb)
- Price in first year of sale
- 229.00 AUS $
- Literature/Schematics (1)
- - - Manufacturers Literature (AWA Manufacturers Supervised Service.)
- Literature/Schematics (2)
- J.R. Publications Television Service Handbook (L.J. Series Group 14, April 1971, Page A105a.)
Operating Instructions. | 2734 KB |
