AWA (Export) 1007 Ch=C77

Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

Data
Forum
Pictures
Collections

  • Year
  • 1947
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 307769

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s); Export model
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 105- 250 Volt Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 7 inch = 17.8 cm
  • Power out
  • 4.5 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: AWA 1007 Ch=C77 - Amalgamated Wireless
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 23 x 12 x 10.4 inch / 584 x 305 x 264 mm
  • Notes

  • AWA Special export model.
    Exported to Papua New Guinea, Indonesia and Asian Territories.
    Radio dial was marked with frequency only and no Australian Stations.

    Export models did not have the brand “Radiola" on the dial or cabinet.

    FREQUENCY BANDS;
    (I) 1600-540 kHz .................(187.5-555 M)
    (2) 4.0-1.5 MHz …………… (75-200 M)
    (3) 10-3.7 MHz…………….. (30-81M)
    (4) 15-9.5 MHz………………(20-31.5M)
    (5) 23-14.7 MHz……………..(13-20M)

    Cabinet: Walnut Veneer

    The chassis & cabinet are similar to the Radiola 614T.

    Information from John McIlwaine.

  • Net weight (2.2 lb = 1 kg)
  • 35 lb (35 lb 0 oz) / 15.890 kg
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Technical Information & Service Manual Model 1007)
