AWA (Export) 1536MA

Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

Data
Forum
Pictures
Collections

  • Year
  • 1953/1954
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 193146

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s); Export model
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 100-115; 116-130; 190-220; 221-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Material
  • Bakelite or Plastics (type unknown)
  • from Radiomuseum.org
  • Model: AWA 1536MA - Amalgamated Wireless
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Notes

  • AWA Special export model.
    Exported to Columbo Plan countries in SE Asia.
    Radio dial was marked with frequency only and no Australian Stations.

    Export models did not have the brand “Radiola" on the dial or cabinet.

    FREQUENCY BANDS;
    (I) 1600-540 kHz ....................................... (187.5-555M)
    (2) 7.0 - 2.2 MHz …………………………… (43-143M)
    (3) 22 - 7.0 MHz …………………………… (13.2 -43M)

    Cabinet available in Walnut, Burgundy & Ivory.

    Information from J McIlwaine.

  • Price in first year of sale
  • 31.75 AUS £
  • Circuit diagram reference
  • Australian Official Radio Service Manual Vol. XII
  • Literature/Schematics (1)
  • - - Manufacturers Literature (AWA Technical Information & Service Data.)
  • Author
  • Model page created by Stuart Irwin. See "Data change" for further contributors.
