• Country
• Australia

• Manufacturer / Brand
• Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

• Year
• 1931

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 164773

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 224 224 247 280

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s)

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 190-270 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiola 34E C84 [with 247 tube] - Amalgamated Wireless

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• 4 Valve, AC Powered, Screen Grid TRF Receiver with Linear Power Detection and one stage of audio amplification.

  Chassis:
  The chassis was available in two versions, this Model 34E C84 with a 247 Pentode and an audio frequency compensating filter in the audio amplifier circuit and Model  34E C77 using a 245 Triode audio amplifier.

  Cabinet:
  Consolette cabinet with a Walnut finish.

• Literature/Schematics (1)
• - - Manufacturers Literature (AWA Radiola Service Instruction 1931)

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
