Radiola Forty-Five (45) Ch=C73; Power Unit=D21 Console
Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1930
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 163924
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s); Screengrid 1926-1935
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 190-270 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola Forty-Five Ch=C73; Power Unit=D21 [Console] - Amalgamated Wireless
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
5 Valve, AC powered, TRF Receiver.
Chassis:
The chassis is fitted with a local/distance switch, a phonograph input on the rear and the power circuit can be arranged to use a Magnetic or Dynamic speaker.
The receiver circuit is also used in the Duoforte 45.Cabinet:
Also available as Table Model.
- Price in first year of sale
- 53.50 AUS £
- Literature/Schematics (1)
- - - Manufacturers Literature (AWA Radiola Service Instruction 1930)
AWA Radiola 45 Pamphlet | 627 KB |
- Documents regarding this model
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
