- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1949/1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 200200
AWA Radiola 524M in marble effect plastic.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 200-230; 230-260 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: Radiola 524M - Amalgamated Wireless
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
Colours available in Ivory, Walnut or Burgundy.
See also Hotpoint H55MEY.
- Price in first year of sale
- 23.90 AUS £
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. VIII
- Mentioned in
- AORSM vol.8 P84
- Literature/Schematics (1)
- - - Manufacturers Literature (AWA Technical Information & Service Data.)
- Literature/Schematics (2)
- Australian Official Radio Service Manual AORSM (Volume 8, 1950, Page 84.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
