• Country
• Australia

• Manufacturer / Brand
• Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

• Year
• 1941

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 261700

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 1A7GT 1P5GT 1H5GT 1Q5GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 1.5 & 2 x 45 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.2 W (undistorted)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Radiola 65 - Amalgamated Wireless

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• The chassis for this radio is the same as in the Fisk Radiola 63.

  An optional AC power unit (type 8491) was available with this radio, using a 5V4G rectifier.

• Mentioned in
• Mingay's "Radio Diagram & I.F. Index

• Literature/Schematics (1)
• - - Manufacturers Literature

• Literature/Schematics (2)
• -- Original prospect or advert

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
