Radiola 805GW
Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295490
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-260 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 805GW - Amalgamated Wireless
- Shape
- Console with any shape - in general
- Notes
-
Updated version of AWA Radiola 805GZ. Service data is presently unavailable. Changes may be miniature valves in place of octals. Otherwise it would likely to be electrically the same or similar for service information.
Valve count minus the magic-eye.
- Price in first year of sale
- 217.50 AUS £
- Mentioned in
- - - Manufacturers Literature (AWA sales data)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
