- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1940/1941
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 345788
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 200-260 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Radiola 84Z - Amalgamated Wireless
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
This model is an updated version of Model 84 with the inclusion of a IF filter in parallel with the aerial coil and possible deletion of the loop antenna.
See also Hotpoint Model A65MEZ.
The model label is likely to be a paper sticker glued to the chassis. These paper labels are reputed to go missing due to poor quality glue, making the set harder to properly identify.
- Price in first year of sale
- 16.95 AUS £
- Mentioned in
- HRSA Radiowaves, April 2023.
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
