Radiola Solid State B77Y
Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1971 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 305421
- Number of Transistors
- 5
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Radiola Solid State B77Y - Amalgamated Wireless
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 6.475 x 3.475 x 2 inch / 164 x 88 x 51 mm
- Notes
-
Similar to models B77 & B77Z, but with minor mechanical & electrical changes.
Uses a 9V Eveready type 2362 battery.
Supplied wirth earpiece and carrying case.
- Net weight (2.2 lb = 1 kg)
- 1 lb 4 oz (1.25 lb) / 0.568 kg
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
