Wayfarer - Six Transistor WF63

Americana Industries Inc.; New York ( NY)

Data
Forum
Pictures
Collections

  • Year
  • 1963 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 260454

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Wayfarer - Six Transistor WF63 - Americana Industries Inc.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 2.7 x 4 x 1 inch / 69 x 102 x 25 mm
  • Notes

  • Frequency tuning range: 535-1605kHz.  CD frequencies marked on dial.

    Made in Japan at the Ryukyu Islands.

  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
