- Country
- United States of America (USA)
- Manufacturer / Brand
- United American Bosch (Magneto Corporation); Springfield (MA)
- Year
- 1930
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 32514
-
- alternative name: American Bosch Magneto
- Brand: Essex
- Number of Tubes
- 8
- Main principle
- TRF without regeneration; 2 AF stage(s); Screengrid 1926-1935
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 58 A - United American Bosch Magneto
- Shape
- Console with any shape - in general
- Notes
- One dial (primary tuning control knob). 5 tuned circuits: 3 RF stages and the first bandfilter, then transformer coupling then bandfilter and at last 1 single tuned circuit, detection, AF and push-pull. See also 58B (Collector's guide). This set uses a 60 cycle power supply. This model was also produced in Canada.
- Price in first year of sale
- 144.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Radio College of Canada
- Mentioned in
- Collector's Guide to Antique Radios 4. Edition (RCC Bosch section page 5.)
