AL-811H

Ameritron; Starkville (MS)

Data
Forum
Pictures
Collections

  • Year
  • 1992 ?
  • Category
  • RF (Radio Frequency-) Amplifier
  • Radiomuseum.org ID
  • 290933

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 120 or 240 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AL-811H - Ameritron; Starkville MS
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 13.75 x 8.25 x 15.5 inch / 349 x 210 x 394 mm
  • Notes

  • The Ameritron AL-811H is an 800 watt PEP output linear amplifier that operates from 160 through 15 meters. The AL-811H uses four 811A tubes in a class AB2 grounded grid circuit.
    Maximum input is 85W.
    Power output is 400W AM, 600W CW and 800W SSB.

    The AL-811H/HY is shipped factory wired for 120 volt, 50/60 Hz power mains.
    The AL-811HX/HY export model is shipped factory wired for 240 volt, 50/60 Hz power mains.



  • Net weight (2.2 lb = 1 kg)
  • 30 lb (30 lb 0 oz) / 13.620 kg
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
