- Country
- Netherlands
- Manufacturer / Brand
- Amroh NV (Radio Bulletin monthly), Muiden
- Year
- 1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 282343
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 3
- Main principle
- Crystal or Solid State Detector with Amplifer
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 2 x 4.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 0.125 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Ion - Amroh NV Radio Bulletin
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 280 x 170 x 160 mm / 11 x 6.7 x 6.3 inch
- Notes
-
Amroh model Ion is the extension of the combination of Amroh models Neutron and UN-51 with an A.F. end stage using RCA transistor 2N408.
This model is equipped with the Amroh Duplex cabinet. Loudspeaker Peerless type H460 (200 Ohm) was recommended.
- Mentioned in
- Radio Bulletin (August 1959)
- Author
- Model page created by Rob Majoor. See "Data change" for further contributors.
