Ontvanger 0-V-1 UN-33
Amroh NV (Radio Bulletin monthly), Muiden
- Country
- Netherlands
- Manufacturer / Brand
- Amroh NV (Radio Bulletin monthly), Muiden
- Year
- 1954
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 120215
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Main principle
- TRF with regeneration; 1 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case, TUBES VISIBLE
- from Radiomuseum.org
- Model: Ontvanger 0-V-1 UN-33 - Amroh NV Radio Bulletin
- Shape
- Chassis only or for «building in»
- Notes
- Steckspulen für sechs Bereiche (80 m, 40 m, 20 m, 49 m, 31 m, 25 m), Köpfhörer benötigt (2000 Ohm).
- Mentioned in
- Buch: Ing.M.van Geelkerken, "Jongens Radio", Bussum: De Muiderkring, 1971, pag.55-62
- Literature/Schematics (1)
- Zeitschrift: Radio Bulletin, Oktober 1954
- Author
- Model page created by Aren van Waarde. See "Data change" for further contributors.
