Apparecchio di Prova per Tiristori UK 808/S

Amtron, (High-Kit, Amtroncraft); Milano

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 319918

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 50/60 Hz: 115; 220; 250 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Apparecchio di Prova per Tiristori UK 808/S - Amtron, High-Kit, Amtroncraft;
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 230 x 135 x 165 mm / 9.1 x 5.3 x 6.5 inch
  • Notes

  • Strumento di prova per tiristori. Consente di testare la corrente di gate con 4 portate da 0,1 a 100 mA e la tensione di gate con 2 portate da 0 a 10 V.

    Utilizza 8 diodi raddrizzatori 1N4001,  2 IC L141T1 e 2 LED.

  • Net weight (2.2 lb = 1 kg)
  • 1.490 kg / 3 lb 4.5 oz (3.282 lb)
  • Mentioned in
  • -- Original prospect or advert (“Kits Elettronici Amtron” catalogo originale n° 8 1974/75.)
  • Literature/Schematics (1)
  • "CQ Elettronica" edizioni CD, numero 9 settembre 1975.
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
