- Country
- Great Britain (UK)
- Manufacturer / Brand
- Antiference Ltd.; Alesbury
- Year
- 1969 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 303920
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 3 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 2303 - Antiference Ltd.; Alesbury
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 7 x 2 x 3.875 inch / 178 x 51 x 98 mm
- Notes
-
Car radio supplied with universal fitting kit and 6 x 4 inch loudspeaker. Push buttons for wavechange and tone control. Suitable for 12 volt DC positive or negative earth.
- Net weight (2.2 lb = 1 kg)
- 2 lb (2 lb 0 oz) / 0.908 kg
- Literature/Schematics (1)
- ERT Service Chart 1749 dated June 25 1970
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
