Tuner A-600AC
Approved Electronic Instr. Corp.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Approved Electronic Instr. Corp.
- Year
- 1952/1953 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 107582
SAMS
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Tuner A-600AC - Approved Electronic Instr.
- Shape
- Chassis only or for «building in»
- Notes
-
The Model A-600AC from Approved Electronic Instrument Corp., 142 Liberty Street, New York 6, NY is a Tuner with Self-Contained Power Supply as a chassis only. Audio output adjustable in 3 steps: 10, 5 and 1 volt.
- Circuit diagram reference
- Rider's Perpetual, Volume 20 covering 1950
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 8-52, set 175, folder 4)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
